Mantra MFS110 L1 fingerprint reader device better than traditional devices in its class, delivering Crypto operation with secure memory, and precise biometric matching making it perfect for ID verification and IT security. Our fingerprint reader is a secured, rugged fingerprint scanner that ensures consistent image quality and precise results. This fingerprint reader is designed for many biometric-based identification applications. It is certified as FBI PIV-071006 for the compliant fingerprint scanner. This device has IP54 certification, which indicates that it is protected from dust and splashing water.The scanner is based on optical technology, which assures high-quality fingerprint scanning even when dusty, dirty or rough fingers are scanned. Developed for law enforcement, IT security, border administration, and national ID programs. Its highly sophisticated crypto operation and ergonomically design makes it excellent performing and secured biometric device in the industry for field operations.
Mantra MFS110 L1 Driver Click to Download.
MANTRA MFS110 L1 Biometric Finger Capture Device
Mantra MFS110 L1 Driver Click to Download.
Fingerprint Sensor Type: Optical Sensor
Spatial Resolution: 500 DPI +/- 2%
Platen Area: 14.0 mm x 17.0 mmImage size: 276 x 336 PixelsImage Grayscale: 256 (8 - Bit Gray Level)Light Source: Red LEDMaximum Acquisition time (Placement to Template): < 2 SecApprox. Dimension (L x W x H): 61(L) x 91(W) x 54(H) mmApprox. Weight: 0.140 kgCapture mode: Auto capture with built-in quality check(incorporates NIST quality considerations)
SecurityParameters Specification Crypto operation : Hardware base RSA2048 Key Generation, AES-GCM-256, SHA-256, TRNG support Secure Memory : TEE support by the device. Secure memory support key wraping feature Secure Boot : Secure boot support by the device Electrical
Parameters Specification Operating Voltage : 5V +/- 5% (USB Powered Device) Operating Current : < 90 ma Stand by Current : 50 mA Interface : USB 2.0 Environmental
Parameters Specification Operating Temperature : 0 to 50 °C Storage Temperature : 0 to 50 °C Humidity (Operating / Storage) : < 90% RH, Non-condensing Compliant To Following Standard
Parameters Specification Biometric Data Interchange Format : ISO 19794-2 for minutiae & ISO 19794-4 for Image Template in Encrypted PID Data Block Environmental, Health and Safety : RoHS Safety : EN/IEC 62368-1, IS 13252 (Part 1) EMI / EMC Compliance : CE, FCC Part 15B Image Quality Compliance : FBI PIV *, STQC * IP Rating : IP54 Device Driver : WHQL Certified Operating System : Windows x86 & x64, Linux, Android
